Traceable Pressure/Vacuum Gauge with a NIST Traceable Calibration Certificate; -14.7 to 29.0 psi

(0)No Reviews yet
$495.55 $583.00
2 – 9$480.98
10 +$466.40
SKU: 3166 (CC)
Item Number: 3166
Model Number: 3166 (98766-90)
Manufacturer: Control Company
Brand: Traceable
MPN: 3166
Condition: New


Traceable® Pressure / Vacuum Gauge, –14.70 to 29.0 PSI with a NIST Traceable® Calibration Certificate (each)

Displays answer in eight different units. Meter is accurate to 1% full-scale plus 1 digit. Jumbo-size digits are 3/8-inch-high. Computer output allows it to be connected to a computer or data logger for monitoring and keeping results. To assure accuracy an individually serial-numbered Traceable® Certificate is provided from our ISO 17025 calibration laboratory accredited by A2LA. It indicates traceability to standards provided by NIST (National Institute of Standards and Technology).

At the touch of a button the unit may be zeroed. Memory key recalls highest and lowest readings. A DATA HOLD button freezes the display to capture readings. Transducer has 1/4-inch NPT male-threaded end. Cable is 40 inches. Supplied with Traceable® Certificate, transducer sensor and 9-volt alkaline battery. Size is 7 x 3 x 1-1/2 inches and weight is 9-1/2 ounces. Replacement battery Cat. No. 1112.

This unit features computer output. To utilize this feature, connect the unit to a PC with an accessory Data Acquisition System. (SOLD SEPARATELY)

Product Type: Pressure / Vacuum Gauge
Brand: Traceable
Range: Max: 29 psi
Accuracy: 1% full-scale plus 1 digit
Overall Dimensions: 7 x 3 x 1-1/2 inches
Includes: Traceable® Certificate, transducer sensor, 9-volt alkaline battery
