AFM-1530-0CD
Images are for representation only. Actual product may differ in size, color or options.
A&F Machine V-5 Piston Metering Pump, Simplex
5/8" Piston Head Diameter.
14.4 - 72.0 GPD (gallons per day), 0.6 - 3.0 GPH (gallons per hour), 1.3 - 6.4 ounces per minute
54.5 - 272.5 LPD (liters per day), 2.28 - 11.4 LPH (liters per hour), 37.8 - 189.0 milliliters per minute
Output rated at 1000 PSI (68.9 BAR) maximum pressure.
30 Strokes per Minute. Adjustable stroke length control, minimum stroke rate 20% of maximum.
*** WITHOUT Motor
Wet End Materials: Carbon Steel (STANDARD)
High pressure, low volume, reciprocating plunger, positive displacement chemical metering pump. Heavy duty speed reducer drive mechanism.
Includes: pressure relief valve and instruction manual.
5/8" Piston Head Diameter.
14.4 - 72.0 GPD (gallons per day), 0.6 - 3.0 GPH (gallons per hour), 1.3 - 6.4 ounces per minute
54.5 - 272.5 LPD (liters per day), 2.28 - 11.4 LPH (liters per hour), 37.8 - 189.0 milliliters per minute
Output rated at 1000 PSI (68.9 BAR) maximum pressure.
30 Strokes per Minute. Adjustable stroke length control, minimum stroke rate 20% of maximum.
*** WITHOUT Motor
Wet End Materials: Carbon Steel (STANDARD)
High pressure, low volume, reciprocating plunger, positive displacement chemical metering pump. Heavy duty speed reducer drive mechanism.
Includes: pressure relief valve and instruction manual.
| Product Type: | Piston Metering Pump, Mechanically Driven |
| Brand: | A&F Machine Products |
| Product Line: | V-5 |
| Class: | Simplex |
| Max Flow (GPH): | 3 |
| Max Flow (GPD): | 72 |
| Max Pressure (PSI): | 1000 |
| Max Viscosity (CPS): | 2,000 |
| Max Strokes per Minute: | 30 |
| Flow Control: | Manual stroke length adjustment (0 to 100%) |
| Turn Down Ratio: | 5 : 1 |
| Head/Fittings: | CS (Carbon Steel) |
| Valve Balls: | S6 (316 SS) |
| Valve / Seat / O-Ring: | Nickel Plated Copper Seal |
| Motor: | NO MOTOR, 56 FRAME |
| Connections: | 1/4" FNPT |
| Operating Modes: | Manual |
| Net Weight: | 75 lbs |
| Overall Dimensions: | 23 x 14.125 x 8 inches |
| Includes: | Pressure Relief Valve and Owners Manual |
