AFM-1818-0CD
Images are for representation only. Actual product may differ in size, color or options.
A&F Machine V-5 Piston Metering Pump, Simplex.
144.0 - 720.0 GPD (gallons per day), 6.0 - 30.0 GPH (gallons per hour), 12.8 - 64.0 ounces per minute
544.74 - 2723.7 LPD (liters per day), 22.8 - 114.0 LPH (liters per hour), 378.0 - 1890.0 milliliters per minute
Output rated at 100 PSI (6.89 BAR) maximum pressure.
1-1/2" diameter piston.
Fully adjustable stroke length control 0-100% (recommended minimum stroke length 20%). 60 SPM (strokes per minute).
It is ideal for use in chemical feed to boilers, waste water treatment, the pulp and paper industry and related applications where a controlled volume of chemical treatment is required.
Connections: 1" NPT Male.
Motor Type: NEMA 56 Foot Mount Motor Connection (Coupling Drive).
Drive Motor: 0CD = WITHOUT Motor.
Wet End Materials: Carbon Steel.
Includes: pressure relief valve and instruction manual.
144.0 - 720.0 GPD (gallons per day), 6.0 - 30.0 GPH (gallons per hour), 12.8 - 64.0 ounces per minute
544.74 - 2723.7 LPD (liters per day), 22.8 - 114.0 LPH (liters per hour), 378.0 - 1890.0 milliliters per minute
Output rated at 100 PSI (6.89 BAR) maximum pressure.
1-1/2" diameter piston.
Fully adjustable stroke length control 0-100% (recommended minimum stroke length 20%). 60 SPM (strokes per minute).
It is ideal for use in chemical feed to boilers, waste water treatment, the pulp and paper industry and related applications where a controlled volume of chemical treatment is required.
Connections: 1" NPT Male.
Motor Type: NEMA 56 Foot Mount Motor Connection (Coupling Drive).
Drive Motor: 0CD = WITHOUT Motor.
Wet End Materials: Carbon Steel.
Includes: pressure relief valve and instruction manual.
| Product Type: | Piston Metering Pump, Mechanically Driven |
| Brand: | A&F Machine Products |
| Product Line: | V-5 |
| Class: | Simplex |
| Max Flow (GPH): | 4 |
| Max Flow (GPD): | 96 |
| Max Pressure (PSI): | 500 |
| Max Viscosity (CPS): | 4,000 |
| Max Strokes per Minute: | 18 |
| Flow Control: | Manual stroke length adjustment (0 to 100%) |
| Turn Down Ratio: | 5 : 1 |
| Head/Fittings: | CS (Carbon Steel) |
| Valve Balls: | S6 (316 SS) |
| Valve / Seat / O-Ring: | Nickel Plated Copper Seal |
| Motor: | NO MOTOR, 56 FRAME |
| Connections: | 1/2" FNPT |
| Operating Modes: | Manual |
| Net Weight: | 64 lbs |
| Overall Dimensions: | 24 x 14.125 x 8 inches |
| Includes: | Pressure Relief Valve and Owners Manual |
