PUL-CCR20DX7F5
Images are for representation only. Actual product may differ in size, color or options.
Dual-Station Black Iron Corrosion Coupon Rack with Flow Control Valve for ASTM Monitoring
This dual-station corrosion monitoring rack is engineered for side-stream sampling in industrial water systems. Built with black iron piping and mounted on a Unistrut frame, it includes outlet and flow control valves for stable, ASTM-compliant testing. Ideal for hot water applications, the system supports standard corrosion coupons and is hydrostatically tested to exceed industry standards.
Specifications
- Model: CCR20DX7F5
- Stations: 2
- Mounting: Unistrut frame
- Piping: 3/4″ Schedule 40 black iron
- Flow Control: 5 GPM valve
- Standards: Built to ASTM specifications
Features
- Hydrostatically tested for enhanced system performance
- Outlet ball valve for easy isolation
- Flow control valve ensures consistent sampling
- Compatible with ASTM corrosion coupons
- Wall-mountable design for streamlined installation
Applications
- Cooling tower corrosion monitoring
- Boiler water diagnostics
- Closed-loop and once-through cooling systems
| Product Type: | Corrosion Coupon Rack |
| Brand: | Pulsafeeder |
| Material: | Iron |
| Color: | Black |
| Max Pressure (PSI): | 250 psi (17.3 bar), 212 °F (100 °C) |
| Flow Control: | Flow control valve 5 GPM. |
| Connections: | 3/4 in. (19 mm) black iron piping Schedule 40 |
| Mount Type: | Unistrut |
| Sections: | 2 Station |
| Overall Dimensions: | Unistrut Mounted: 16 in. H x 22 in. W (406 x 559 mm) |
| Includes: | Outlet ball valve, Flow control valve 5 GPM. |
| Notes: | System does not include coupons |
