A&F Machine V-5 Piston Metering Pump (WITHOUT MOTOR), Simplex

(0)No Reviews yet
$2,516.25 $3,050.00
QuantityPrice
1$2,516.25
SKU: AFM-1360-0CD-SS
Item Number: AFM-1360-0CD-SS
Model Number: 1360-0CD-SS
Manufacturer: A&F Machine Products
Brand: A&F Machine Products
MPN: 1360-0CD-SS
Condition: New

New

A&F Machine V-5 Piston Metering Pump, Simplex.
7.68 - 38.4 GPD (gallons per day), 0.32 - 1.6 GPH (gallons per hour), 0.682 - 3.41 ounces per minute
29.1 - 145.5 LPD (liters per day), 1.212 - 6.06 LPH (liters per hour), 20.2 - 101.0 milliliters per minute
Output rated at 1000 PSI (68.9 BAR) maximum pressure.
3/8" diameter piston.
Fully adjustable stroke length control 0-100% (recommended minimum stroke length 20%). 60 SPM (strokes per minute).
It is ideal for use in chemical feed to boilers, waste water treatment, the pulp and paper industry and related applications where a controlled volume of chemical treatment is required.
Connections: 1/4" NPT Female.
Motor Type: NEMA 56 Foot Mount Motor Connection (Coupling Drive).
Drive Motor: 0CD = WITHOUT Motor (mount your own NEMA 56 Foot Mount 1750 RPM motor).
Wet End Materials: SS = 303 Stainless Steel.
Includes: pressure relief valve and instruction manual.


Product Type: Piston Metering Pump, Mechanically Driven
Brand: A&F Machine Products
Product Line: V-5
Class: Simplex
Max Flow (GPH): 1.6
Max Flow (GPD): 38.4
Max Pressure (PSI): 1000
Max Viscosity (CPS): 1,000
Max Strokes per Minute: 60
Flow Control: Manual stroke length adjustment (0 to 100%)
Turn Down Ratio: 5 : 1
Head/Fittings: SS (303 SS)
Valve Balls: S6 (316 SS)
Valve / Seat / O-Ring: Nickel Plated Copper Seal
Motor: NO MOTOR, 56 FRAME
Connections: 1/4" FNPT
Operating Modes: Manual
Net Weight: 60 lbs
Overall Dimensions: 23 x 14.125 x 8 inches
Includes: Pressure Relief Valve and Owners Manual
