A&F Machine V-10 Piston Metering Pump (WITHOUT MOTOR), Triplex
A&F Machine V-10 Piston Metering Pump (WITHOUT MOTOR), Triplex
Per Head 67.2 - 336.0 GPD (gallons per day), 2.8 - 14.0 GPH (gallons per hour), 6.0 - 30.0 ounces per minute
254.4 - 1272.0 LPD (liters per day), 10.6 - 53.0 LPH (liters per hour), 176.66 - 883.3 milliliters per minute
Per Head output rated at 500 PSI (34.5 BAR) maximum pressure.
Per Head 1" Piston Head Diameter.
Per Head: fully adjustable stroke length control 0-100% (recommended minimum stroke length 20%). 60 SPM (strokes per minute).
High pressure, low volume, reciprocating plunger, positive displacement chemical metering pump. Heavy duty speed reducer drive mechanism.
56C flange mount motor drive.
Drive Motor: NO MOTOR, 56C FRAME
Wet End Materials: SS = 303 Stainless Steel
Includes: pressure relief valve (3) and instruction manual.
| Product Type: | Piston Metering Pump, Mechanically Driven |
| Brand: | A&F Machine Products |
| Product Line: | V-10 |
| Class: | Triplex |
| Max Flow (GPH): | 30 |
| Max Flow (GPD): | 720 |
| Max Pressure (PSI): | 500 |
| Max Viscosity (CPS): | 2,000 |
| Max Strokes per Minute: | 60 |
| Flow Control: | Manual stroke length adjustment (0 to 100%) |
| Turn Down Ratio: | 5 : 1 |
| Head/Fittings: | SS (303 SS) |
| Valve Balls: | S6 (316 SS) |
| Valve / Seat / O-Ring: | Nickel Plated Copper Seal |
| Motor: | NO MOTOR, 56C FRAME |
| Connections: | 1/2" FNPT |
| Operating Modes: | Manual |
| Net Weight: | 115 lbs |
| Overall Dimensions: | 25 x 19 x 11 inches |
| Includes: | Pressure Relief Valves and Owners Manual |
