Cole‑Parmer Data Logging Light Meter with NIST‑Traceable Calibration
Cole‑Parmer Data Logging Light Meter with NIST‑Traceable Calibration
The Cole‑Parmer® Digi‑Sense Data Logging Light Meter provides precision light intensity measurements in lux or footcandles for indoor and outdoor environments. Its expanded measurement range up to 400,000 lux (40,000 ft‑c) supports a wide variety of lighting applications, from safety compliance to productivity optimization. Each unit includes a NIST‑traceable calibration report with data supplied by InnoCal, ensuring reliable, standards‑based performance.
Key Features
- Precalibrated to NIST‑traceable standards for guaranteed accuracy
- Expanded measurement range: 0 to 400 klux (0 to 40 kft‑c)
- Silicon photodiode with spectral response filter for ±3% precision
- Record up to 87,000 measurements for extended data analysis
- Data logging software with graphical display for fast interpretation
- 2‑year warranty
More About This Item
The Digi‑Sense data logging light meter is designed for precision light intensity measurements in lux or footcandles. It helps meet lighting codes and standards, ensuring safety, comfort, and quality control in laboratories, industrial facilities, and environmental monitoring applications. The NIST‑traceable precalibration ensures dependable measurements right out of the box.
User‑selectable lux or ft‑c units, max/min, and hold functions provide flexible control over measurement readings. The included software allows graphical data viewing, recording, and downloading via USB connectivity for deeper analysis.
Technical Specifications
- Measurement Range: 0 to 40,000 ft‑c; 0 to 400,000 lux
- Resolution: 0.01 ft‑c; 0.1 lux
- Accuracy: ±3% of reading ±0.5% full‑scale; ±4% of reading ±10 digits above 10,000 lux
- Functions: Datalogging, min/max/hold, record/recall, auto power‑off, low‑battery indicator, user‑selectable lux or ft‑c
- Display: 4000‑count backlit LCD
- Data Logging Capacity: 87,000 readings
- Interface: USB
- Dimensions: 6‑3/8″ H × 2″ W × 1″ D (16 × 5 × 2.7 cm)
- Power: 3 × AAA batteries (included)
- Description: Data Logging Light Meter with NIST‑Traceable Calibration
- Warranty: 2 years
Included Accessories
- USB cable
- Software CD
- Canvas carrying case
- Three AAA batteries
- NIST‑traceable calibration report with InnoCal data
This Cole‑Parmer® data logging light meter is ideal for laboratories, environmental monitoring, industrial safety, and any application requiring precise, standards‑based light measurement. It supports lighting QA/QC workflows and regulated environments.
Guaranteed to have at least one year of calibration remaining on certificate.
| Product Type: | Digital Light Meter |
| Brand: | Cole-Parmer |
| Material: | Probe: Silicone light diode with spectral response filter |
| Range: | 0 to 400,000 Lux; 0 to 40,000 Fc |
| Resolution: | 0.01 |
| Accuracy: | ±3% reading ±0.5% full-scale (<10,000 Lux), ±4% reading ± 10 digits (>10,000 Lux) |
| Cable Length: | 4.9 feet |
| Display: | LCD, backlit |
| Operating Modes: | Data logging, record/recall, min/max/hold, auto power-off, low-battery indicator, user-selectable lux or ftc |
| Warranty: | 2 years |
| Overall Dimensions: | 2 x 6.5 x 1 inches |
| Includes: | USB cable, software, canvas carrying case, three AAA batteries, and NIST-traceable calibration report with data supplied by InnoCal. |
| Notes: | Stores 99 readings manually on unit, or 87,000 manual/automatic readings when connected to PC. Used for Data logging, record/recall, min/max/hold, auto power-off, low-battery indicator, user-selectable lux or ftc |
