Lovibond® W100/OG/50 Optical Glass Cell – 50 mm Path Length

The Lovibond® W100/OG/50 is a high‑quality optical glass cell designed for precise colour and photometric measurements across a broad spectral range. Manufactured from heat‑fused optical glass, the cell offers exceptional durability, chemical resistance, and optical clarity from 340 nm to 2500 nm. Bevelled edging ensures smooth placement into instrument cell holders, while blemish‑free optical surfaces support highly repeatable, low‑scatter measurements. This 50 mm path‑length cell is suitable for Lovibond® PFXi instruments and standard spectrophotometers that accept 12.5 mm wide cells.

• Item Number: 601070
• Model: W100/OG/50
• Material: High‑quality heat‑fused optical glass
• Spectral Range: 340 nm to 2500 nm
• Path Length: 50 mm
• Cell Dimensions: 12.5 mm wide × 40 mm high
• Compatibility: PFXi 195 (with cell holder 131907), PFXi 880/950/995 (with cell holder 137530), EC 2000 Pt‑Co, EC 3000 Gardner, and standard spectrophotometers accepting 12.5 mm cells
• Construction: Heat‑fused for strength and long service life
• Edges: Bevelled for easy placement
• Optical Quality: Blemish‑free surfaces for accurate, repeatable readings
• Included: One optical glass cell
