Ohaus MB120 Moisture Analyzer
Images are for representation only. Actual product may differ in size, color or options.
Ohaus MB120 Moisture Analyzer
The MB120 delivers functionality and precision that you can rely on, and is easy to operate and clean – you can test more samples in less time! Advanced features such as a temperature guide help to analyze optimum drying temperature, and methods and results storage allows statistical analysis of measurements. Three levels of user management ensure data safety - set up and lock temperature settings and method parameters with administrator access.
Applications
Percent Moisture Determination, Percent Moisture Regain Determination, Percent Solid Determination, Weighing
Display
4.3" TFT color touchscreen display
Operation
Power cord (included)
Communication
RS232 with GLP/GMP data output, USB Host and USB Device (included)
Construction
Metal base, ABS top housing, halogen heat source, stainless steel pan support, stainless steel pan handler, in-use cover
Design Features
Seven shut-off criteria (manual, timed, autofree %/s, autofree mg/s, A30, A60 and A90), four drying profiles (standard, fast, ramp and step), storage up to 100 methods and 1000 test results for all methods, user guide, 40°C to 230°C heating temperature range (1°C increments), 13 operational languages
The MB120 delivers functionality and precision that you can rely on, and is easy to operate and clean – you can test more samples in less time! Advanced features such as a temperature guide help to analyze optimum drying temperature, and methods and results storage allows statistical analysis of measurements. Three levels of user management ensure data safety - set up and lock temperature settings and method parameters with administrator access.
Applications
Percent Moisture Determination, Percent Moisture Regain Determination, Percent Solid Determination, Weighing
Display
4.3" TFT color touchscreen display
Operation
Power cord (included)
Communication
RS232 with GLP/GMP data output, USB Host and USB Device (included)
Construction
Metal base, ABS top housing, halogen heat source, stainless steel pan support, stainless steel pan handler, in-use cover
Design Features
Seven shut-off criteria (manual, timed, autofree %/s, autofree mg/s, A30, A60 and A90), four drying profiles (standard, fast, ramp and step), storage up to 100 methods and 1000 test results for all methods, user guide, 40°C to 230°C heating temperature range (1°C increments), 13 operational languages
| Product Type: | Analyzer |
| Brand: | Ohaus |
| Class: | Moisture |
| Range: | 0 % - 100 % |
| Capacity: | 120 g |
| Readability: | 0.001 g / 0.01% |
| Repeatability (S.D.): | 0.05% (3 g sample), 0.015% (10 g sample) |
| Pan Size: | 3.5 in (90 mm) |
| Housing: | ABS |
| Power Supply: | Main power cord |
| Display: | Touchscreen |
| Interface: | Bi-directional USB and RS-232 |
| Units of Measure: | Gram, %MC, %RG, %DC |
| Overall Dimensions: | 8.3 x 7.7 x 14.0 in (211 x 180 x 355 mm) |
| Includes: | in-use cover, user-guide, power cord |
| Notes: | Shut-off Criteria: Manual, Timed, Automatic - Preset Weight Loss/Time, Custom - User Set Weight Loss/Time, Custom-User Set Moisture% Loss/Time |
