Corrosion Coupon Rack – Dual Station CPVC, ASTM-Compatible Side-Stream Monitor for Heated Water Environments
Images are for representation only. Actual product may differ in size, color or options.
Corrosion Coupon Rack – Dual Station CPVC, ASTM-Compatible Side-Stream Monitor for Heated Water Environments
The CCR20B is a specialized dual-station rack for side-stream corrosion sampling in high-temperature industrial water systems. Built from Schedule 80 CPVC and mounted on a 0.50″ HDPE panel, it supports ASTM coupons for reliable monitoring in heated environments.
Specifications
- Stations: 2
- Mounting: 0.50″ HDPE panel
- Piping: 3/4″ Schedule 80 CPVC
- Max Pressure: 150 psi (10.3 bar)
- Max Temperature: 212 °F (100 °C)
Features
- Threaded vertical coupon holders for ASTM-standard coupons
- Wall-mounted corrosion testing configuration
- Suited for elevated water temperatures
Applications
- Hot water corrosion diagnostics
- Industrial boiler system monitoring
- Side-stream sampling in high-temp conditions
| Product Type: | Corrosion Coupon Rack |
| Brand: | Pulsafeeder |
| Material: | CPVC |
| Color: | Gray |
| Max Pressure (PSI): | 150 psi (10.4 bar), 212 °F (100 °C) |
| Connections: | 3/4 in. (19 mm) CPVC piping Schedule 80 |
| Mount Type: | 1/2 inch HDPE Panel |
| Sections: | 2 Station |
| Overall Dimensions: | Panel Size: 16 in. H x 22 in. W (406 x 559 mm) |
| Notes: | System does not include coupons |
