Dual-Station Clear PVC Corrosion Coupon Rack with Flow Meter and Y Strainer for ASTM Monitoring
Images are for representation only. Actual product may differ in size, color or options.
Dual-Station Clear PVC Corrosion Coupon Rack with Flow Meter and Y Strainer for ASTM Monitoring
The CCR20X4X8AX9 is a dual-station corrosion monitoring rack designed for side-stream sampling in industrial water systems. Constructed with clear Schedule 80 PVC piping and mounted on an HDPE panel, it includes a 3/4″ water flow meter rated to 130 °F and a Y strainer for debris filtration. This configuration supports ASTM-standard coupons and provides visual flow inspection for enhanced diagnostics.
Specifications
- Model: CCR20X4X8AX9
- Stations: 2
- Mounting: HDPE panel
- Piping: 3/4″ Clear Schedule 80 PVC
- Flow Meter: 3/4″ water flow meter, max 100 psi @ 130 °F
- Strainer: Y strainer for particulate removal
- Standards: Built to ASTM specifications
Features
- Clear PVC piping allows visual inspection of flow conditions
- Integrated flow meter for real-time monitoring
- Y strainer protects downstream components from debris
- Wall-mountable HDPE panel for streamlined installation
- Hydrostatically tested for enhanced reliability
- Compatible with ASTM corrosion coupons
Applications
- Cooling tower corrosion monitoring
- Boiler water diagnostics
- Closed-loop and once-through cooling systems
| Product Type: | Corrosion Coupon Rack |
| Brand: | Pulsafeeder |
| Material: | PVC |
| Color: | Gray |
| Max Pressure (PSI): | 100 psi (10.4 bar) @ 130 °F (54 °C) |
| Connections: | 3/4 in. (19 mm) PVC piping Schedule 80 |
| Mount Type: | 1/4 inch Poly Panel |
| Sections: | 2 Station |
| Overall Dimensions: | Panel Size: 16 in. H x 22 in. W (406 x 559 mm) |
| Includes: | 3/4 in. hot/cold water flow meter, Y Strainer, Clear PVC pipe sections. |
| Notes: | System does not include coupons |
