Graham Condenser – 24/40 Joint, 300 mm (each)
Images are for representation only. Actual product may differ in size, color or options.
Graham Condenser – 24/40 Joint, 300 mm (each)
Extended‑length Graham condenser with coiled inner tube and water‑jacketed outer tube for superior vapor cooling. Equipped with 24/40 joints at both ends and screw‑thread connectors for 1/4 in OD plastic tubing. Constructed from borosilicate glass and autoclavable for repeated laboratory use.
Specifications
- Product Number: CNG300
- Joint Size: 24/40 (top and bottom sockets)
- Effective Length: 300 mm
- Hose Connections: Screw‑thread, fit 1/4 in (OD) plastic tubing
- Material: Borosilicate glass
- Autoclavable: Yes
Features
- Increased coil length for greater cooling capacity
- Water‑jacketed design for efficient condensation
- Standard 24/40 joints for easy integration
- Durable, autoclavable borosilicate glass
Applications
Used in distillation assemblies where additional cooling length is beneficial.
| Brand: | United Scientific |
| Material: | Borosilicate Glass |
| Length: | 300 mm |
| Autoclavable: | Yes |
