Graham Condenser – 24/40 Joint, 500 mm (each)
Images are for representation only. Actual product may differ in size, color or options.
Graham Condenser – 24/40 Joint, 500 mm (each)
Extra‑long Graham condenser with coiled inner tube and water jacket, delivering maximum cooling surface area for demanding distillation applications. Features 24/40 joints at both ends and screw‑thread connectors for 1/4 in OD plastic tubing. Fabricated from borosilicate glass and autoclavable for repeated use.
Specifications
- Product Number: CNG500
- Joint Size: 24/40 (top and bottom sockets)
- Effective Length: 500 mm
- Hose Connections: Screw‑thread, fit 1/4 in (OD) plastic tubing
- Material: Borosilicate glass
- Autoclavable: Yes
Features
- Maximum coil length for superior cooling performance
- Water‑jacketed design for efficient condensation
- Standard 24/40 joints for system integration
- Durable, autoclavable borosilicate glass construction
Applications
Best suited for high‑capacity distillation systems requiring extended cooling length.
| Brand: | United Scientific |
| Material: | Borosilicate Glass |
| Length: | 500 mm |
| Autoclavable: | Yes |
