Digital Binocular Microscope (each)
Images are for representation only. Actual product may differ in size, color or options.
Digital Binocular Microscope (each)
The VE-D300 digital microscope was designed for professional use. It has all the virtues of a professional biological microscope, in addition to being equipped with a 5.0MP digital camera. It includes an easy-to-use software compatible with Windows operating systems, practical for editing, storing and observing images in real time. It can perform measurements in a wide range of units. Compatible with Windows 10 and lower operating systems.
The VE-D300 is ideal for the identification and analysis of biological samples in areas such as biology, medicine, pathology and microbiology. Adaptable to the needs of the user, the VE-D300 offers optional configurations for several applications.
SPECIFICATIONS
EYEPIECES: PL 10X/20 mm 360° rotary with rubber eyecups and ± 5 mm diopter adjustment in both eyepieces.
HEAD: Binocular Gemel type, 30° inclined with interpupillary distance adjustment between 50 – 75 mm/1.96"- 2.95" and integrated 5.0MP digital camera.
NOSEPIECE: Quadruple nosepiece with anti-slip grip and click-stops, mounted on high-tension ball bearings.
OBJECTIVES: 4X, 10X, 40X (S) and 100X (S) (oil), infinity corrected plan achromatic optics and color ring for easy identification
STAND: Stative, robust and reinforced with epoxy paint finish.
STAGE: Two-Layer stage with X-Y coaxial movement, 5.90" x 5.51", vernier, millimeter scale (3.46" x 2.36"), clamp and height adjustment with stop.
CONDENSER: Abbe, N.A. 1.25 with height adjustment screw. Equipped with an adapter for optional configurations (not included).
DIAPHRAGM: Iris with filter holder.
FOCUSING: Coarse and fine anti-slip control knob with 0.001 mm precision, 200 graduations per micrometer turn (0.2 mm) and tension adjustment.
ILLUMINATION: 3W Kohler LED with intensity control and field diaphragm in the lamp.
POWER SUPPLY: 110-240V, 50/60 Hz, AC Adapter.
DIMENSIONS: 8.07" x 18.42" x 14.96"
ACCESSORIES INCLUDED
Dust cover.
Immersion oil.
Power cord.
Software CD.
USB cable.
ACCESSORIES NOT INCLUDED
Dark field set.
LED fluorescence illuminator.
Phase contrast kit.
Simple polarization set
WARRANTY
10-years limited warranty
The VE-D300 digital microscope was designed for professional use. It has all the virtues of a professional biological microscope, in addition to being equipped with a 5.0MP digital camera. It includes an easy-to-use software compatible with Windows operating systems, practical for editing, storing and observing images in real time. It can perform measurements in a wide range of units. Compatible with Windows 10 and lower operating systems.
The VE-D300 is ideal for the identification and analysis of biological samples in areas such as biology, medicine, pathology and microbiology. Adaptable to the needs of the user, the VE-D300 offers optional configurations for several applications.
SPECIFICATIONS
EYEPIECES: PL 10X/20 mm 360° rotary with rubber eyecups and ± 5 mm diopter adjustment in both eyepieces.
HEAD: Binocular Gemel type, 30° inclined with interpupillary distance adjustment between 50 – 75 mm/1.96"- 2.95" and integrated 5.0MP digital camera.
NOSEPIECE: Quadruple nosepiece with anti-slip grip and click-stops, mounted on high-tension ball bearings.
OBJECTIVES: 4X, 10X, 40X (S) and 100X (S) (oil), infinity corrected plan achromatic optics and color ring for easy identification
STAND: Stative, robust and reinforced with epoxy paint finish.
STAGE: Two-Layer stage with X-Y coaxial movement, 5.90" x 5.51", vernier, millimeter scale (3.46" x 2.36"), clamp and height adjustment with stop.
CONDENSER: Abbe, N.A. 1.25 with height adjustment screw. Equipped with an adapter for optional configurations (not included).
DIAPHRAGM: Iris with filter holder.
FOCUSING: Coarse and fine anti-slip control knob with 0.001 mm precision, 200 graduations per micrometer turn (0.2 mm) and tension adjustment.
ILLUMINATION: 3W Kohler LED with intensity control and field diaphragm in the lamp.
POWER SUPPLY: 110-240V, 50/60 Hz, AC Adapter.
DIMENSIONS: 8.07" x 18.42" x 14.96"
ACCESSORIES INCLUDED
Dust cover.
Immersion oil.
Power cord.
Software CD.
USB cable.
ACCESSORIES NOT INCLUDED
Dark field set.
LED fluorescence illuminator.
Phase contrast kit.
Simple polarization set
WARRANTY
10-years limited warranty
| Product Type: | Microscope |
| Brand: | VELAB |
| Head: | Binocular |
| Overall Dimensions: | 22 x 11 x 22 in |
