Biological Monocular Microscope w/ Quadruple Nose Piece (each)
Images are for representation only. Actual product may differ in size, color or options.
Biological Monocular Microscope w/ Quadruple Nose Piece (each)
The VE-M5 microscope can fulfill all kinds of basic and advanced procedures. Its area of application is not limited to education, it can be applied in clinical laboratories for observation of blood samples, parasite identification and urinary sediment sample observation, due to its immersion objective.
SPECIFICATIONS
EYEPIECE WF 10X/18 mm with block screw.
HEAD Monocular head, 45° inclined, 360° rotatable.
NOSEPIECE Quadruple nosepiece with click-stops.
OBJECTIVES 4X, 10X, 40X (S) and 100X (S) (oil), achromatic optics, metallic finish, anti-slip grip and color ring for easy identification.
STAND Stative, robust and reinforced with epoxy paint finish.
STAGE Two-layer stage, with X-Y coaxial movement, 5.11" x 5.11", vernier, millimeter scale, clamp and height adjustment with stop.
CONDENSER Abbe, N.A. 1.25 with height adjustment screw.
DIAPHRAGM Iris type with filter holder.
FOCUSING Coarse and fine anti-slip control knob with tension adjustment.
ILLUMINATION LED with intensity control
WEIGHT 1 2.32 lb / 5.58kg
DIMENSIONS 10.04" x 12.99" x 12.99" / 255 x 329 x 329 mm
POWER SUPPLY Three 1.2V AA rechargeable batteries (included) for 4 hours of continuous operation. 110-240V, 50/60 Hz AC adapter.
ACCESSORIES INCLUDED
AC/DC adapter.
Adapter cable reel device.
Blue filter.
Dust cover.
Immersion oil..
WARRANTY
10-years limited warranty.
The VE-M5 microscope can fulfill all kinds of basic and advanced procedures. Its area of application is not limited to education, it can be applied in clinical laboratories for observation of blood samples, parasite identification and urinary sediment sample observation, due to its immersion objective.
SPECIFICATIONS
EYEPIECE WF 10X/18 mm with block screw.
HEAD Monocular head, 45° inclined, 360° rotatable.
NOSEPIECE Quadruple nosepiece with click-stops.
OBJECTIVES 4X, 10X, 40X (S) and 100X (S) (oil), achromatic optics, metallic finish, anti-slip grip and color ring for easy identification.
STAND Stative, robust and reinforced with epoxy paint finish.
STAGE Two-layer stage, with X-Y coaxial movement, 5.11" x 5.11", vernier, millimeter scale, clamp and height adjustment with stop.
CONDENSER Abbe, N.A. 1.25 with height adjustment screw.
DIAPHRAGM Iris type with filter holder.
FOCUSING Coarse and fine anti-slip control knob with tension adjustment.
ILLUMINATION LED with intensity control
WEIGHT 1 2.32 lb / 5.58kg
DIMENSIONS 10.04" x 12.99" x 12.99" / 255 x 329 x 329 mm
POWER SUPPLY Three 1.2V AA rechargeable batteries (included) for 4 hours of continuous operation. 110-240V, 50/60 Hz AC adapter.
ACCESSORIES INCLUDED
AC/DC adapter.
Adapter cable reel device.
Blue filter.
Dust cover.
Immersion oil..
WARRANTY
10-years limited warranty.
| Product Type: | Microscope |
| Brand: | VELAB |
| Product Line: | VELAB |
| Class: | Educational |
| Grade: | Intermediate |
| Power Supply: | Main power cord / Internal rechargeable battery |
| Body: | Stative Epoxy Paint Finish |
| Condenser: | 1.25 N.A. Abbe with height adjustment screw |
| Eyepieces: | 18 mm F.D. |
| Eyepiece Type: | Widefield |
| Eyepiece Magnification: | 10X |
| Focusing: | Coarse and fine anti-slip control knob with tension adjustment |
| Head: | Monocular |
| Illumination: | LED with variable intensity control |
| Nosepiece: | Quadruple nosepiece with click-stops |
| Objective Magnification: | 4X, 10X, 40X, 100X (Oil) |
| Objective Type: | Achromatic optics, metallic finish, anti-slip grip and color ring for easy identification |
| Stage: | Double plate with X-Y coaxial movement, 130 x 130 mm / 5.11 x 5.11 inches, vernier, millimeter scale, clamp and height adjustment with stop |
| Viewing Head: | 45° Inclination; 360° Rotatable |
| Warranty: | 10 years limited |
| Overall Dimensions: | 10 x 16 x 13 in |
| Includes: | AC/DC Adapter, Adapter cable reel device, Blue filter, Dust cover, Immersion oil, Operation manual |
