Traceable® 9002TR Dual-Input Data Logging Thermocouple Thermometer, Type K/J

Traceable® 9002TR Dual-Input Data Logging Thermocouple Thermometer, Type K/J

The Traceable® 9002TR Dual-Input Data Logging Thermocouple Thermometer is designed for laboratory, industrial, manufacturing, HVAC, food processing, research, and quality control applications. Supporting both Type K and Type J thermocouple probes, this handheld thermometer provides dual-channel measurements, temperature differential calculations, onboard data logging, and USB connectivity for comprehensive temperature monitoring and documentation.

Key Features

• Accepts both Type K and Type J thermocouple probes
• Dual-input design supports simultaneous measurement from two probes
• Displays temperature differential between channels (T1-T2)
• Stores up to 18,000 readings for data logging applications
• USB interface for data transfer and reporting
• Relative time stamp function for event tracking
• Electronic offset function compensates for probe variations
• Displays minimum, maximum, and average readings
• Selectable °F, °C, and Kelvin temperature units
• Hold function freezes displayed measurements
• Automatic power-off helps conserve battery life
• Large backlit LCD for low-light operation
• Low-battery indicator
• Includes Traceable® Certificate from an A2LA-accredited calibration laboratory
• 1-year warranty

Product Details

The 9002TR Thermocouple Thermometer combines advanced temperature measurement and data logging capabilities in a compact handheld instrument. Its dual-channel design allows users to monitor two temperature points simultaneously while displaying the temperature difference between probes for process validation, equipment testing, and quality assurance applications.

Compatible with both Type K and Type J thermocouples, the thermometer supports temperature measurements across a wide range, making it suitable for laboratory research, industrial processes, environmental testing, HVAC diagnostics, and food safety monitoring.

Internal memory stores up to 18,000 readings, allowing temperature data to be collected over extended periods without continuous supervision. Logged data can be transferred to a computer through the USB interface for analysis, reporting, documentation, and record retention.

Additional features include Min/Max/Avg functions, relative time stamping, data hold capability, and electronic offset adjustment for improved measurement accuracy. The backlit LCD display ensures readability in low-light environments.

Each thermometer includes an individually numbered Traceable® Certificate documenting traceability to recognized national measurement standards. Guaranteed to have at least one year of calibration remaining on the certificate.

Specifications

• Measurement Type: Thermocouple Thermometer
• Probe Channels: 2
• Accepted Probe Types: Type K and Type J Thermocouples
• Temperature Range: -210 to 1372°C (-346 to 2501°F)
• Resolution: 0.1°; 1° Above 1000°
• Accuracy: ±0.5% of Reading +1.0°C
• Accuracy Below -100°C: ±0.5% of Reading +2.0°C
• Data Logging: Yes
• Memory Capacity: 18,000 Readings
• Temperature Differential: Yes (T1-T2)
• Min/Max/Avg Function: Yes
• Relative Time Stamp: Yes
• Data Hold Function: Yes
• Electronic Offset: Yes
• Temperature Units: °F, °C, Kelvin
• Interface: USB
• Display: Backlit LCD
• Low Battery Indicator: Yes
• Dimensions: 6.5 × 2.5 × 1.125 in.
• Battery: Three AAA Batteries
• Description: Dual-Input Data Logging Thermocouple Thermometer, Type K/J
• Warranty: 1 Year

Includes

• Traceable® Certificate
• Two Type K Bead Wire Temperature Probes
• USB Data Transfer Cable
• Data Logging Software
• Three AAA Batteries

Ideal for industrial process monitoring, laboratory testing, HVAC diagnostics, food safety verification, manufacturing quality control, equipment validation, environmental testing, furnace monitoring, research applications, and temperature differential measurements requiring traceable calibration and data logging capabilities.
