Traceable® 9003TR Four-Input Data Logging Thermocouple Thermometer, Type K/J

Traceable® 9003TR Four-Input Data Logging Thermocouple Thermometer, Type K/J

The Traceable® 9003TR Four-Input Data Logging Thermocouple Thermometer is designed for laboratory, industrial, manufacturing, HVAC, food processing, research, and quality control applications. Supporting up to four Type K or Type J thermocouple probes simultaneously, this handheld thermometer provides multi-point temperature monitoring, differential measurements, onboard data logging, and USB connectivity for comprehensive temperature analysis and reporting.

Key Features

• Accepts up to four thermocouple probes simultaneously
• Compatible with both Type K and Type J thermocouple probes
• Four-channel temperature monitoring for multi-point measurements
• Displays temperature differentials for process analysis and validation
• Stores up to 18,000 readings for data logging applications
• USB interface for data transfer and reporting
• Relative time stamp function for event tracking
• Electronic offset function compensates for probe variations
• Displays minimum, maximum, and average measurements
• Selectable °F, °C, and Kelvin temperature units
• Data hold function freezes readings for convenient viewing
• Automatic power-off helps conserve battery life
• Large backlit LCD for low-light operation
• Low-battery indicator
• Includes Traceable® Certificate from an A2LA-accredited calibration laboratory
• 1-year warranty

Product Details

The 9003TR Thermocouple Thermometer delivers reliable multi-point temperature measurement in a compact handheld design. Its four-input capability allows users to simultaneously monitor temperatures at multiple locations, making it ideal for process validation, thermal profiling, equipment troubleshooting, environmental monitoring, and quality assurance applications.

Compatible with both Type K and Type J thermocouples, the instrument supports a wide temperature range suitable for applications from cryogenic testing to high-temperature industrial processes. Multiple channels can be monitored at once while comparing temperature differences between measurement points.

Internal memory stores up to 18,000 readings for unattended monitoring and documentation. Logged data can be downloaded through the USB interface using the included software for analysis, reporting, record retention, and compliance documentation.

Advanced features include Min/Max/Avg recording, relative time stamping, data hold capability, electronic offset compensation, and selectable temperature units. These tools support accurate temperature investigations, process verification, and quality control activities.

The backlit LCD display provides clear visibility in low-light environments, while battery-saving features help maximize operating life during field and laboratory use.

Each thermometer includes an individually numbered Traceable® Certificate documenting traceability to recognized national measurement standards. Guaranteed to have at least one year of calibration remaining on the certificate.

Specifications

• Measurement Type: Thermocouple Thermometer
• Probe Channels: 4
• Accepted Probe Types: Type K and Type J Thermocouples
• Temperature Range: -210 to 1372°C (-346 to 2501°F)
• Resolution: 0.1°; 1° Above 1000°
• Accuracy: ±0.5% of Reading +1.0°C
• Accuracy Below -100°C: ±0.5% of Reading +2.0°C
• Temperature Differential Measurement: Yes
• Data Logging: Yes
• Memory Capacity: 18,000 Readings
• Min/Max/Avg Function: Yes
• Relative Time Stamp: Yes
• Data Hold Function: Yes
• Electronic Offset Function: Yes
• Temperature Units: °F, °C, Kelvin
• Interface: USB
• Display: Backlit LCD
• Low Battery Indicator: Yes
• Dimensions: 6.5 × 2.5 × 1.125 in.
• Number of Included Probes: 4
• Battery: Three AAA Batteries
• Description: Four-Input Data Logging Thermocouple Thermometer, Type K/J
• Warranty: 1 Year

Includes

• Traceable® Certificate
• Four Type K Bead Wire Temperature Probes
• USB Data Transfer Cable
• Data Logging Software
• Three AAA Batteries

Ideal for multi-point process monitoring, thermal profiling, laboratory testing, HVAC diagnostics, food processing, manufacturing quality control, environmental testing, equipment qualification, furnace and kiln monitoring, and applications requiring accurate four-channel thermocouple measurements with data logging and traceable calibration.
