Lovibond® BD600 Respirometric BOD Meter – 6-Position Wastewater Analyzer
Images are for representation only. Actual product may differ in size, color or options.
Lovibond BD600 Respirometric BOD Meter – 6-Position Wastewater Analyzer
The Lovibond BD600 (Catalog No. 2444460) is a precision respirometric system for determining Biochemical Oxygen Demand (BOD) in wastewater samples. Designed for automatic, mercury-free measurement using electronic pressure sensors, it supports up to six simultaneous samples with real-time data logging. The system includes a large graphic display, USB and SD card interfaces, and a remote control for non-intrusive monitoring. Ideal for municipal, industrial, and environmental labs seeking reliable BOD analysis with minimal sample prep.
Key Features
- Model: BD600
- Catalog No.: 2444460
- Measurement Principle: Manometric (mercury-free electronic pressure sensor)
- Measurement Range: 0–40, 0–80, 0–200, 0–400, 0–800, 0–2000, 0–4000 mg/L BOD
- Measurement Duration: Selectable from 1 to 28 days
- Display: Large backlit graphic display with BOD curve visualization
- Interfaces: USB and SD card
- Autostart: Yes
- Sample Tracking: Integrated LED indicators and sample ID assignment
- Remote Control: Included for incubator viewing
- Compliance: CE EMC (DIN EN 61326)
Dimensions & Weight
- Unit size: 181 × 230 × 375 mm
- Weight: 4.1 kg (5.8 kg with bottles, batteries, and stirring unit)
Performance
- Measuring Stations: 6
- Storage Interval: Hourly (Day 1), every 2 hours (Day 2), daily (Day 3–28)
- Power Supply: 100–240 V / 50–60 Hz or 3 × C-size batteries
- Protection Class: IP53
Applications
- Wastewater treatment process control
- Environmental monitoring
- Industrial effluent analysis
Included Accessories
- 6 Sensor heads
- Control unit with batteries
- Inductive stirring unit
- Power supply with Y-cable
- 6 Sample bottles
- 6 Rubber gaskets
- 6 Magnetic stirring rods
- 50 ml Potassium hydroxide solution (45%)
- 50 ml Nitrification inhibitor
- Overflow measuring flasks (157 ml and 428 ml)
- Remote control
- User manual and guarantee sheet
Optional Accessories
- Inductive Stirring Unit: 2444456
- BOD Sensor: 2444470
- Y-Cable: 2444475
- Remote Control: 2444481
- USB Cable (3m): 2444482
- Magnetic Stirring Rod: 418633
- Rubber Gasket (4.5 cm): 418636
- Magnetic Rod Remover: 418638
- BOD Sample Flask (500 ml): 418644
- Overflow Measuring Flasks: 418654–418660
| Product Type: | BOD Measurement |
| Brand: | Lovibond |
| Product Line: | Lovibond |
