Pulsafeeder Variable Area In‑Line Flow Meter, 0.50" NPT (0.5–5 GPM)
Images are for representation only. Actual product may differ in size, color or options.
Pulsafeeder Variable Area In‑Line Flow Meter, 0.50" NPT (0.5–5 GPM)
The Pulsafeeder 33‑023‑02 is a compact variable area in‑line flow meter optimized for low‑flow water systems. With a 0.50" NPT connection and a flow range of 0.5–5 GPM (1.8–18 LPM), it delivers precise visual indication for dosing, conditioning, and small‑scale process applications.
This model features a 316 stainless steel float and guide rods for smooth, stable operation inside a chemically resistant polysulfone body. Viton® O‑rings provide secure sealing. Rated to 150 psi and 212°F at zero pressure, the unit installs easily using threaded joint and panel‑mount fittings.
- Part Number: 33‑023‑02
- Connection Size: 0.50" NPT
- Flow Range: 0.5–5 GPM (1.8–18 LPM)
- Body Material: Polysulfone
- Float & Guide Rods: 316 Stainless Steel
- O‑Rings: Viton®
- Max Pressure: 150 psi (10 bar)
- Max Temperature: 212°F (100°C at 0 pressure)
- Accuracy: ±4% of full scale
| Product Type: | Flow Meter |
| Brand: | Pulsafeeder |
